Rain Room for sale

Other names: Interactive Rain Room, Interactive Water Room, Storm Room, Interactive Storm Room

How does a Rain Room work?

A digital rain room is an interactive water attraction that takes the form of a room. Its ceiling is provided with a large number of evenly distributed nozzles. The water flowing through those nozzles is controlled by electronics. Water drops form falling images and interesting visual effects. The water circulates in a closed circuit. The drops that are created in the interactive rain room fall into the through at the bottom. Afterward, the water is filtered and pumped back to the top.

The interactive rain room is delivered as a separate unit, which is installed by our technicians on the site indicated by the client. The installation site can be indoors or outdoors.

The rain room requires a water treatment station, a through for the falling water, and piping connecting all these elements at the installation site to work properly. Our offer includes a water treatment plant as a separate product. The piping and the through are usually provided by a local hydraulic company.

Available rain room sizes

Area

The digital water room has a modular structure. Each module has a size of 1m x 1m and is equipped with 80 valves and 480 nozzles. It is therefore possible to configure the size of the room with the accuracy of full square meters.

Height

The rain rooms may have any height. This does not affect the price of the water room but may increase the cost of the water supply system. It should also be borne in mind that in case of high outdoor installations the wind may disperse the falling water drops.

What can an interactive water room display?

Water flow in the rain room is controlled electronically. The water drops create three-dimensional shapes. These can be some interesting visual effects from our library or any graphics sent by the client.

Our software allows you to combine several animations. The digital rain room can store up to 9 in its memory. The machine can be controlled remotely using a tablet with a dedicated application. When the printing is completed the program is looped.

Operating the interactive rain room

The machine is operated with an Android device (usually a tablet). It can be used to load programs (image files, GIF animations) and turn the rain room on and off. Using the tablet, the spectators can draw any black and white picture or inscription in the android application. When the start button is pressed the digital water room immediately stops displaying the default program and presents the shapes drawn by a spectator three times. Then it returns to displaying the default program. The range of data transmission via Bluetooth is about 15 meters. The client can place the tablet on the rack or give it to the technical service.

Possibilities

DMX receiver

Synchronize the interactive rain room with music and light, connect it to other devices using DMX512 protocol. This is how you can turn the printing machine on or off at any time, or switch between different programs.

Lighting

Please refer to our technical documentation for more details on lighting possibilities. Optionally, we can supply LED lamps mounted from the bottom or top, integrated with the interactive rain room.

Presence sensors

Thanks to the installation of the sensors it is possible to walk through the rain room, passing the drops of falling water without getting wet. The printed image opens in front of the people passing through it.​

Anti-splash mats

It is recommended to cover the tank with anti-splash mats to limit the splashing. We can supply mats on request.

Contact us to get technical documentation and drawings

Installation requirements and conditions

Terms and conditions of sale

Please read the general terms and conditions that applies to all sales

Payment terms

  • 30% of the order amount to confirm the order
  • 70% of the order amount 1 week after the assembly

Discounts

  • -5% if ordered at least 50 days before the expected delivery date
  • -10%, if ordered at least 100 days before the expected delivery date
  • -15% if ordered at least 150 days before the expected delivery date

Logistics

The rain room is delivered Ex Works. It means that all transportation costs and travel expenses borne for the first installation and later servicing are covered by the client.

The client is responsible to cover the shipment, pay any local taxes and duties, and costs of any additional documentation (eg. ATA carnet) required by law or authorities at the destination.

If the installation is in Europe, we offer shipment as optional service.

Delivered products and services

  • Rain room set
  • Control system + programming
  • Tablet to operate the rain room
  • 6 - 30-day assembly and testing done by 2 technicians
  • 1-year guarantee (extended for a fee)

Installation site requirements

The rain room can be installed provided that the installation place meets all the technical requirements mentioned in the Technical Specification that is available on request. The following elements should be ensured by the client:

  • Water treatment system (pump, filter, chemical treatment; can be ordered from us) according to our specification
  • Piping between the machine and the water treatment system (usually done by a local plumber)
  • Water tank (basin; usually done by a local construction company)
  • Lighting (may be ordered from us)
  • Shipment (may be ordered from us)
  • Transportation for our technicians (if shipment not ordered from us)
  • Accommodation for our technicians
  • Custom duties and taxes
  • A lift or a ladder (if lower than 4m) for technicians to access the mounting place

The machine is fixed to metal ceiling mounts with winches. They are sent to the client in advance, and they should be bolted in a desired position before the installation takes place. Their documentation is sent on request.

Water images are visible best against a dark background.

To reduce water splashes, the water tank should be covered with splash reducing mats. They can be delivered on request.

Under regular conditions, the falling water will not be spraying out of the tank noticeably. However, it cannot be ruled out that the water will wet the floor as a result of wind, spectators touching streams of water, during assembly and disassembly.

The rain room is rainproof but it cannot work during a storm.

Winds over 7 knots (3 on the Beaufort scale) can deform falling images and cause water to fall outside the tank or give the people nearby a wetting. To reduce the risk of wind, it is worth placing the rain room in front of a wall or artificial background, protecting it against the wind, putting the machine sideways to the wind, avoiding the machine placed in constricted spaces, e.g. between buildings, where the wind speed increases.

Installation

It usually takes a number of consecutive days to install and test the rain room:

  • The machine is assembled on the ground below the ceiling mounts.
  • The winches are connected to the ceiling mounts and to the machine
  • The machine is raised
  • Our technicians use ladders or a lift to fix the machine to the ceiling mounts, and to connect cables and pipes
  • The rain room is programmed and tested. The hydraulic installation has to be operational

All the technical requirements must be fulfilled before the installation. It must be possible to run the pump and the tank must be filled with water during the installation. In that time, the machine and the ground below should be freely accessible to our technicians. They should have a possibility to run and test it for at least 6 hours per day.

The client should determine the work schedule in advance, and inform about all the safety requirements (like obligatory Personal Protective Equipment) and mandatory permits at the place of installation.

Our insurance does not allow our technicians to perform activities other than work with the equipment we provide. In particular:

  • They may not assemble or disassemble the machine housing and its surroundings supplied by the client.
  • They may not perform any plumbing or electrical work
  • They cannot drill holes or use anchor bolts in order to fix the ceiling mounts

When the installation is complete, our technicians will provide information on how to operate and maintain the machine to a person designated by the client.

Additional installation fees

If the installation site requirements are not met, the installation may be postponed or prolonged until the client resolves all the problems. In this case, an extra assembly fee is charged for each additional assembly day.

Guarantee

Different components of our machines are covered by different types of Guarantee:

  • The software and the components manufactured by us that are subject to wear and tear are covered by the Endless Guarantee. In order to keep them operational the client is required to pay the Maintenance Fee.
  • Other components manufactured by us are covered with 1 Year Guarantee. The Guarantee for those components can be extended by paying the Guarantee Extension Fee.
  • Components that are manufactured and branded by other companies (e. g. pumps, filters, lamps and construction elements) are covered by their manufacturers' guarantee.

Endless Guarantee and Maintenance Fee

We guarantee the proper operation of the software and all components that are subject to wear and tear that we manufacture. The guarantee is not limited in time.

To keep those components operational, the client is required to pay the Maintenance Fee. It is paid in advance quarterly or annually for the entire period. It is calculated for every component according the following list:

  • 0,15 EUR/hour of operation for the BT Controller Software
  • 0,17 EUR/hour of operation for every 1x1m Printing Module

The prices are adjusted for inflation.

The minimal fee is calculated based on four machine hours per day, irrespective of actual usage time.

The Maintenance and Guarantee Extension Fee is not payable for the first year of operation. It is due from the client starting from the second year of operation.

The fee should be paid before the end of previous billing period. Otherwise the digital water curtain may be electronically blocked until the payment is made.

A document with the guarantee terms and conditions is provided on demand.

Advantages of Endless Guarantee

The water room is a highly complex product. Its fast-moving parts are subject to wear and tear. To provide clients with the deepest possible experience, we developed our own valves which are even 6 times more durable than the ones used by our competitors.

The digital water curtain systems offered by the competition may have a very limited lifespan. After some time, the machines may deteriorate and deliver a negative experience to the spectators. Owners of those systems are exposed to very high repair or maintenance costs after the guarantee has expired. The digital water curtains produced by our competitors are usually proprietary systems that may be repaired only by the manufacturer. This usually significantly increases the servicing costs. The repair cost may actually be as high as that of a new machine.

 To keep our clients satisfied, we decided to reduce the initial cost of our machines significantly, and introduce a low annual fee.

The initial cost of our machines is lower by 40-50% when compared to our competitors’ solutions.

Our clients are happy that they can avoid unexpected costs in the future, and they appreciate the transparency of our offer. They are glad to receive the highest quality and everlasting product that impresses even after years of operation.

One Year Guarantee with Optional Extension

The components that are produced by us and are not covered by the Endless Guarantee are covered by 1 Year Guarantee with a possible extension for the following years.

The Guarantee Extension Fee is equal to 5% of the price of the components.

Maintenance and servicing

The installation has to be inspected every 3 years.

In an unlikely case of malfunction, we will ask the client to designate a person to carry some simple servicing tasks. Examples of those tasks are mentioned in the Technical Specification. Those actions are aimed at fixing the problem or finding the source of malfunction before our arrival.

All maintenance and service works as well as any spare parts are covered by the guarantee. However, the client has to settle all shipping costs for the spare parts along with all the expenses for the transportation and accommodation for our technicians.
